OEM Final Drive WBM-702CT Manufacturer, Factories

Model No.: WBM-702CT Used for 2.5-3.5 ton Compact Track Loader. Build-in flushing valve for closed loop application. OEM quality with One Year warranty. Interchangeable with Bonfiglioli 702 CT Track Drive.

Send Inquiry

Product Description

◆ Brief Introduction

WBM-702CT Track Drive is our new designed Final Drive which integrated with high efficiency hydraulic motor and high strength planetary gearbox. It is widely used for Skid Steer Loaders, Compact Track Loaders, Pavers, Dozers, Soil Compactors and other Crawler Equipment.

Model	Max Working Pressure	Max. Output Torque	Max. Output Speed	Speed	Oil Port	Application
WBM-702CT	27.5 MPa	3500 N.m	100 rpm	2-speed	5 ports	2.5-3.5 Ton

★ Key Features

✔ Designed for closed hydraulic circuit.

✔ Build-in flushing valve.

✔ Axial Piston Motor with high efficiency.

✔ Double speed Motor with large ration for widely usage.

✔ Build-in parking brake for safety.

✔ Extremely compact volume and light weight.

✔ Reliable quality and high durability.

✔ Travel smoothly with very low noisy.

✔ Automatic speed changing function is optional.

■ Widely Applications

WBM Track Motors can be suitable for most of the Track Loaders in the market. Such as BOBCAT, CASE, CATERPILLAR, JOHN DEERE, DITCH WITCH, EUROCOMACH, GEHL, IHI, JCB, KOMATSU, MANITOU, MUSTANG, NEW HOLLAND, TAKEUCHI, TEREX, TORO, VERMEER, VOLVO, WACKER NEUSON, YANMAR and other main brand Compact Loaders.

Summary:

WBM-700 series Track Drive is our new designed Travel Motor for closed loop applications. It is mainly used in Skid Steer Loaders and Compact Track Loaders. These Final Drives are with the same specifications and connecting dimensions with Bonfiglioli 700 series Track Drives. We are also making the Track Drives which are interchangeable with the main brands such as Sauer-Danfoss BMVT, Nabtesco TH-VB, DANA CTL Spicer Torque-hub, etc. We can also design the Motor size and connection as your OEM Final Drives.

⚙ Connection Dimensions

Frame orientation diameter	210mm
Frame bolt pattern	8-M16
Frame holes P.C.D.	240mm
Sprocket orientation diameter	210mm
Sprocket bolt pattern	12-M16
Sprocket holes P.C.D.	245mm
Flange distance	70mm
Approximate weight	60kg

Note: Both flange holes patterns can be made as required.

Frequently Asked Questions (FAQ)

Q1: What types of equipment is the WBM-702CT Track Drive compatible with?

A: It is specifically designed for Skid Steer Loaders, Compact Track Loaders, Pavers, Dozers, and other crawler equipment in the 2.5 to 3.5-ton range.

Q2: Can this motor replace other major brands?

A: Yes, our WBM-700 series is designed to be interchangeable with Bonfiglioli 700 series, Sauer-Danfoss BMVT, Nabtesco TH-VB, and DANA CTL Spicer Torque-hub.

Q3: Does it feature an integrated braking system?

A: Yes, the WBM-702CT includes a built-in parking brake to ensure safety during operation.

Q4: What is the benefit of the built-in flushing valve?

A: The built-in flushing valve helps in maintaining the cleanliness and temperature of the hydraulic oil within a closed circuit, extending the life of the motor.

Q5: Is it possible to customize the connection dimensions?

A: Absolutely. We can design the motor size and connection dimensions to match your specific OEM Final Drive requirements.

Q6: What speed configurations are available?

A: It is a 2-speed motor, and an automatic speed changing function is available as an optional feature.
