OEM Track Drive 710 C2K Factory, Factories

Model No.: W710 C2 K 25-30 ton Excavator Travel Motor. OEM quality with One Year warranty. Quickly delivery within 3 days (standard models). Interchangeable with TM40, MAG-170VP-3800, GM38VB, JMV147 Travel Motors.

Send Inquiry

Product Description

▶ Video Display

Model	Max Output Torque (Nm)	Max Working Pressure (Mpa)	Max Output Speed (r/min)	Applicable Tonnage(T)
WTM-40	46000	34.5	50	25-30T

📋 Brief Introduction

700CK series Track Drive motors are integrated Travel Drive motors for crawler excavators and other track drive machines. Extreme compactness, lightweight, efficiency and smooth operation are the key features of the 700CK series track drives. It is powered by integrated axial piston motor and worked with high strength big toque reducing gearboxes.

★ Key Features

✔ Swash-plate Piston Motor with high efficiency.

✔ Double speed Motor with large ration for widely usage.

✔ Rugged design.

✔ High torque capacity.

✔ High load capacity.

✔ Compact design.

✔ Rotating output flange with large PCD suitable for sprocket.

✔ Freelwheel in for easily transportation.

⚙ Technical Specifications

Motor Displacement	95/180 cc/r
Working pressure	31.5 Mpa
Speed control pressure	2~7 Mpa
Ratio options	48
Max. torque of Gearbox	43200 N.m
Max. speed of Gearbox	50 rpm
Machine application	25~30 Ton

🔗 Connection Details

Frame connection diameter	300mm
Frame flange bolt	30-M16
Frame flange P.C.D.	340mm
Sprocket connection diameter	402mm
Sprocket flange bolt	30-M16
Sprocket flange P.C.D.	440mm
Flange distance	98mm
Approximate weigth	380kg (840lbs)

💡 Summary & Compatibility

710 C2 K series Track Drive is with the similar dimensions with most of the famous brands in market such as Nachi Travel Motor, KYB Travel Motor, Eaton Track Drive, and other Final Drives. So it widely used in the OEM and aftersales market to replace Nachi, Kayaba, Eaton, Nabtesco, Doosan, Bonfiglioli, Brevini, Comer, Rexroth, Kawasaki, Jeil, Teijin Seiki, Tong Myung and other Hydraulic Final Drive Motors.

Our models include 700C2K, 700-2C2K, 701C2K, 702C2K, 704C2k, 705C2k to 710C2K. We are also making 700C1H, 701C1, 703C2H, 705C2H, 706C3H, 707 C2B, 709C3B, 710C2B, 711C3B, 713C3B, 715C3B, 717C3H, and the full series of 700C Travel Drives.

Wide Brand Application: Suitable for most Excavators including Airman, Atlas Copco, Bobcat, Case, Caterpillar, Daewoo/Doosan, Gehl, Hitachi, Hyundai, IHI, JCB, John Deere, Kobelco, Komatsu, Kubota, Liebherr, LiuGong, Lonking, Lovol, Mitsubishi, Nachi, New Holland, Nissan, Pel Job, Rexroth, Samsung, Sany, Sandvik, Schaeff, SDLG, Sumitomo, Sunward, Takeuchi, Terex, Wacker Neuson, Wirtgen, Volvo, XCMG, XGMA, Yanmar, Yuchai, Zoomlion and other main brand Excavators.

? Frequently Asked Questions (FAQ)

1. Can this travel motor replace my original Nachi or KYB motor? Yes, the 710 C2 K series is designed with dimensions similar to major brands like Nachi, KYB, and Eaton, making it a perfect replacement for OEM and aftersales markets.

2. What machine tonnage is the WTM-40 suitable for? The WTM-40 model and 700CK series are ideally suited for crawler excavators in the 25 to 30-ton range.

3. Does it support different speed modes? Yes, these are integrated double-speed motors with large ratios, allowing for versatile usage across different operating conditions.

4. What are the key advantages of the 700CK series? The key features include extreme compactness, lightweight design, high torque capacity, and smooth operation through an integrated axial piston motor.

5. Is it compatible with my specific excavator brand like Caterpillar or Komatsu? Our travel motors are compatible with a wide range of brands including Caterpillar, Komatsu, Hitachi, Volvo, Sany, and many other leading manufacturers.

6. How does the motor handle heavy loads? The motor features a rugged design with high load and torque capacities, specifically engineered for the demanding environments of track-driven machinery.
