A4VG series 180cc/r displacement variable swash plate type piston pump is a widely used closed loop hydraulic pump for high-pressure circumstances. The max pressure could be made at 450 bar. It is widely used in Agricultural machinery, Construction machinery, Aerial Lifts, and other special vehicles.
Frequently Asked Questions
What is the maximum pressure for the A4VG180 pump?
The A4VG series 180cc/r pump can handle a maximum pressure of up to 450 bar, making it ideal for high-pressure hydraulic applications.
Is this pump compatible with Rexroth models?
Yes, the connection dimensions of this pump are designed to be fully interchangeable with the Rexroth A4VG180 series pump.
What applications is the A4VG180 suitable for?
It is widely utilized in closed-loop systems for agricultural machinery, construction equipment, aerial lifts, and various special-purpose vehicles.
Does the pump include an auxiliary pump?
Yes, it features an integrated auxiliary pump specifically for boost and pilot oil supply.
Can I mount additional pumps to the A4VG180?
Yes, the pump features a through drive that allows for the mounting of further pumps up to the same nominal size.
How does the flow direction change in this pump?
The flow direction changes smoothly as the swashplate is moved through the neutral position, ensuring precise control.
