Empower your machinery to conquer any terrain. Our expertise lies in customized, efficiently-assembled undercarriages built from top-grade components. Precision, affordability, and promptness are our promise.
Durability
Engineered for high-stress, heavy-duty applications.
Longevity
Manufactured to last, reducing the need for frequent replacements.
Performance
Improves the overall performance of the equipment and machinery.
Customizable
Can be tailored to meet the specific needs of different machinery.
Service
Comprehensive after-sales service and support system.
Availability
Wide distribution network and quick international shipping times.
Cost-effectiveness
More affordable in the long run due to reduced downtime.
Quality Control
Manufactured to the highest industry standards.
| Model |
Dimensions (mm) |
Machine Weight (Kg) |
| A |
B |
C |
D |
| WSU-02 | 1630 | 1250 | 230 | 400 | 1500-2000 |
| WSU-03 | 1815 | 1460 | 230 | 400 | 2500-3000 |
| WSU-04 | 1895 | 1500 | 300 | 485 | 3000-4000 |
| WSU-05 | 1990 | 1600 | 300 | 530 | 4000-5000 |
| WSU-06 | 2118 | 1591 | 300 | 550 | 5000-6000 |
| WSU-07 | 2795 | 2265 | 350 | 600 | 6000-7000 |
| WSU-08 | 2880 | 2350 | 400 | 600 | 7000-8000 |
| WSU-10 | 3500 | 3202 | 400 | 670 | 9000-10000 |
| WSU-15 | 3800 | 3802 | 400 | 700 | 13000-15000 |
| WSU-20 | 3805 | 3300 | 500 | 720 | 18000-20000 |
| WSU-25 | 4139 | 3400 | 500 | 730 | 22000-25000 |
| WSU-40 | 4000 | 3280 | 500 | 750 | 30000-40000 |
| WSU-50 | 4000 | 3300 | 500 | 830 | 40000-50000 |
| WSU-60 | 4500 | 3800 | 500 | 950 | 50000-60000 |
| WSU-90 | 5000 | 4300 | 600 | 1000 | 80000-90000 |
| WSU-110 | 5500 | 4800 | 600 | 1100 | 100000-110000 |
| WSU-130 | 5500 | 4800 | 700 | 1200 | 120000-130000 |
| WSU-150 | 6000 | 5300 | 900 | 1400 | 140000-150000 |
Ready to optimize your machine's mobility? Let our high-performance solutions drive your success.
Frequently Asked Questions
Can the undercarriage be customized for specific machinery?
Yes, our steel track undercarriages are highly customizable. We can tailor dimensions, load capacities, and components to meet the unique requirements of your specific equipment.
What materials are used to ensure durability?
We use top-grade steel and high-strength components engineered for high-stress applications, ensuring the undercarriage survives heavy-duty use in harsh terrains.
How do I choose the correct model for my machine?
Selection is primarily based on the total weight of your machine. Refer to the "Machine Weight (Kg)" column in our specification table to find the corresponding model.
What are the international shipping times?
Thanks to our wide distribution network, we offer prompt international shipping. Specific times depend on your location, but we prioritize quick dispatch for all global orders.
Is technical support available after purchase?
Absolutely. We provide comprehensive after-sales service and technical support to ensure your undercarriage performs optimally throughout its lifespan.
Why is a steel track undercarriage considered cost-effective?
While the initial investment is standard, the high durability and longevity reduce the frequency of replacements and minimize machine downtime, leading to lower long-term costs.
